With vast and rich industrial experience, we are able offer a superior quality Vibratory Plate Compactors. These products are manufactured and are designed in accordance with global quality standards using superior quality durable raw materials. We offer these compactors at a wide range of industrial specifications to cater the huge industrial demand. Our organization offers this compactor at competitive prices to please our clients.
Uneek® Compactors offers construction and CIVIL industry a Power full yet convenient method of quick & perfect soil compaction. It is Applicable on all types of soil & sub grades as well as broken rocks, Earthgravel, chips, dry concrete, bituminous coarse base, backfills, Plinth fillings, embankments,, foundations, bridge abetments, runway Track, Repair of patches, manholes, level crossings, godown or factory floors, ramps, runways, platforms, salt pans, road shoulders, earth filling for pipe, cable laying, sheets and pilling structures, under floor, canal banks, beds, .etc.
| Model | UK-10 | UK-20 | UK-40 |
| Compaction Capacity | 1/2 ton | 2/3 ton | 4/5 ton |
| Impact force ( Appr.) | 850 kg. | 1300 kg. | 3000 kg. |
| Vibration Frequency (Appr.) | 2100 p/min. | 2000 p/min | 2000 p/min |
| Depth Effect depending upon type of soil | 6 inch | 10 inch | 12 inch |
| Travel Speed | 60 ft. p/min | 65ft p/min | 65ft. p.min |
| Gradient Capacity | 20% | 20% | 20% |
| Compaction Plate Size | 23"* 12" | 32"* 16" | 25"*20" |
| Working Area (per Hour) | 4300 sq.ft. | 4400 sq. ft. | 5500 sq. ft. |
| Total Gross Weight | 130 kg. | 160 kg. | 180 kg. |
| Direction of travel | forward | forward | forward |
| Power Unit | 1.95 HP Greaves petrol/Kerosene engine or Villiers C12 Or 2 Hp Motor with starter | 3.4 HP Greaves Air cooled 4 stroke petrol engine or GK 200 Honda engine or 3Hp electric Motor with starter or 4.4 Hp Greaves Diesel | 4.4 HP Greaves Diesel Engine or 5 HP Electric Motor |
